SKMEI 1471 Analog Digital Watch Instruction Manual

1. Product Overview

The SKMEI 1471 is a versatile analog-digital watch designed for outdoor and daily use. It features a luminous display, 5-bar water resistance, an alarm clock, and a stopwatch function. This manual provides detailed instructions for setting up and operating your watch.

Image 1.1: Front view of the SKMEI 1471 watch, highlighting the digital display and button labels.

The watch combines a traditional analog display with a clear digital screen, offering multiple functions accessible via its side buttons. Its robust design is suitable for various activities.

Image 1.2: Detailed view of the watch face and button functions.

Button Functions:

• MODE Button: Used to cycle through different display modes (Time, Alarm, Stopwatch).
• RESET Button: Used to reset values (e.g., stopwatch) or adjust settings during setup.
• START-STOP Button: Used to start/stop functions (e.g., stopwatch) or select items during setup.
• LIGHT Button: Activates the electroluminescent backlight for visibility in low light conditions.

2. Setup

2.1 Setting Time and Date

1. From the normal time display, press the MODE button three times to enter the time setting mode. The seconds digits will flash.
2. Press the RESET button to cycle through the setting options: Seconds → Hour → Minute → Month → Date → Day of Week.
3. While the desired value is flashing, press the START-STOP button to adjust the value. Hold the button to change values faster.
4. Once all settings are adjusted, press the MODE button to return to the normal time display.

2.2 Setting the Alarm

1. From the normal time display, press the MODE button once to enter the Alarm mode.
2. Press the RESET button once. The hour digits will flash.
3. Press the START-STOP button to adjust the alarm hour.
4. Press the RESET button again. The minute digits will flash.
5. Press the START-STOP button to adjust the alarm minute.
6. Press the MODE button to exit the alarm setting mode.
7. To turn the alarm ON/OFF, in Alarm mode, press the START-STOP button. An alarm icon will appear/disappear to indicate its status.

3. Operating Instructions

3.1 Using the Stopwatch (CHRONO)

1. From the normal time display, press the MODE button twice to enter the Stopwatch mode. The display will show "00:00:00".
2. Press the START-STOP button to start the stopwatch.
3. Press the START-STOP button again to stop the stopwatch.
4. To reset the stopwatch to "00:00:00", press the RESET button while the stopwatch is stopped.
5. To return to the normal time display, press the MODE button.

3.2 Activating the Backlight

Press the LIGHT button at any time to illuminate the digital display. The backlight will remain active for a few seconds.

3.3 12/24 Hour Format

In the time setting mode (after pressing MODE three times), press the START-STOP button while the hour is flashing to toggle between 12-hour (with AM/PM indicator) and 24-hour formats.

4. Maintenance

4.1 Water Resistance

The SKMEI 1471 watch is water-resistant up to 50 meters (5 ATM / 5 Bar). This means it is suitable for daily use, showering, and swimming in shallow water. It is not suitable for diving or snorkeling. Do not operate buttons while the watch is wet or submerged to prevent water ingress.

4.2 Cleaning

To clean your watch, wipe it with a soft, damp cloth. Avoid using harsh chemicals or abrasive materials, as these can damage the watch's finish or strap.

4.3 Battery Replacement

When the display becomes dim or functions become erratic, the battery may need replacement. Battery replacement should ideally be performed by a qualified watch technician to ensure proper sealing and water resistance.

5. Troubleshooting

• Display is blank or dim: The battery may be low or depleted. Replace the battery.
• Incorrect time/date: Re-adjust the time and date settings as described in Section 2.1. Ensure the 12/24 hour format is set correctly.
• Buttons are unresponsive: Ensure the watch is not wet. If the issue persists, a reset may be required (consult a technician) or the battery may be low.
• Water inside the watch: Immediately take the watch to a qualified technician. Do not attempt to open it yourself, as this will void the warranty and compromise water resistance.

6. Specifications

7. Warranty and Support

This product comes with a standard manufacturer's warranty. Please refer to the warranty card included with your purchase for specific terms and conditions. For technical support, service, or warranty claims, please contact the retailer or the manufacturer directly. Keep your purchase receipt as proof of purchase.

For further assistance, you may visit the official SKMEI website or contact their customer service department.
