Velamp IR170EVO Portable Emergency Light and LED Torch

Introduction

The Velamp IR170EVO is a versatile 2-in-1 portable emergency light and LED torch designed to provide reliable illumination during power outages or in situations requiring portable light. This rechargeable device features both a diffuse LED tube for room lighting and a focused LED torch for concentrated illumination. It is equipped with an automatic activation function during power failures, ensuring you are never left in the dark.

The Velamp IR170EVO portable emergency light, shown with its external AC/DC adapter.

Safety Instructions

• Read all instructions before use and retain for future reference.
• Do not expose the device to water or excessive moisture. This product is not waterproof (IP20 rating).
• Keep out of reach of children.
• Use only the provided AC/DC adapter for charging. Using unauthorized adapters may damage the device or pose a fire hazard.
• Do not attempt to open or repair the device. Refer all servicing to qualified personnel.
• Avoid direct eye exposure to the LED light, as it can be very bright.
• Ensure proper ventilation during charging.

Package Contents

Verify that all items are present in the package:

• 1 x Velamp IR170EVO Portable Emergency Light
• 1 x AC/DC Adapter

Product Features and Components

The Velamp IR170EVO combines two lighting functions in one compact unit:

• LED Tube (Diffuse Light): Provides 170 lumens of wide, homogeneous, and anti-glare illumination, ideal for lighting a room.
• 3W High-Power LED (Focus Light): Offers 100 lumens of concentrated light, suitable for use as a flashlight for distance or specific tasks.
• Automatic Power Outage Activation: The light automatically turns on when power is interrupted, provided it is plugged into an outlet.
• Rechargeable Battery: Equipped with a 4V 1000 mAh lead-acid battery, offering approximately 3 hours of autonomy.
• External AC/DC Adapter: Designed for safety and convenience, preventing tripping hazards.

This image highlights the two light sources: the 3W high-power LED for focused light (torch) and the LED tube for diffuse room illumination.

Setup and Charging

Initial Charge

Before first use, fully charge the emergency light for optimal battery performance.

1. Connect the provided AC/DC adapter to the charging port on the emergency light.
2. Plug the adapter into a standard wall outlet.
3. The charging indicator light (if present) will illuminate to show that the device is charging.
4. Allow the device to charge until the indicator light changes or for the recommended duration (refer to specifications for full charge time, typically several hours).

The top view illustrates the charging port location for connecting the AC/DC adapter.

Automatic Emergency Function Setup

To enable the automatic emergency light function:

• Ensure the emergency light is fully charged.
• Keep the device continuously plugged into a wall outlet using the AC/DC adapter.
• In the event of a power failure, the light will automatically turn on, providing illumination.

This image demonstrates how the external AC/DC adapter of the Velamp IR170EVO prevents tripping hazards associated with integrated adapters and long cables.

Operating Instructions

Manual Operation

To manually turn on the light when not plugged in or during normal operation:

1. Locate the power button on the device.
2. Press the button once to activate the diffuse LED tube (lantern mode).
3. Press the button a second time to switch to the focused 3W LED torch mode.
4. Press the button a third time to turn the light off.

Maintenance

Cleaning

To clean the device:

• Ensure the device is unplugged from the power outlet before cleaning.
• Wipe the exterior with a soft, dry cloth.
• Do not use abrasive cleaners, solvents, or harsh chemicals, as these may damage the plastic housing.

Battery Care

To prolong battery life:

• If the device is not used for extended periods, charge it at least once every three months to prevent deep discharge.
• Store the device in a cool, dry place.

Troubleshooting

• Light does not turn on:
  • Ensure the battery is charged. Plug the device into an outlet and allow it to charge.
  • Check if the power button is pressed correctly.
• Automatic emergency function does not activate:
  • Verify that the device is continuously plugged into a live power outlet.
  • Ensure the battery has sufficient charge.
• Short battery life:
  • The battery may require a full charge cycle.
  • Battery performance can degrade over time. If the issue persists, the battery may need replacement (contact support).

Specifications

The emergency light measures 7.5 cm in width, 13 cm in depth, and 18.6 cm in height.

Warranty and Support

For warranty information or technical support, please refer to the documentation included with your purchase or visit the official Velamp website. Keep your proof of purchase for any warranty claims.
