1. Introduction
Thank you for purchasing the UKing ZQ02006 50W LED Moving Head Light. This versatile stage lighting fixture is designed to produce dynamic effects for various events, including parties, bars, clubs, theaters, and weddings. It features 8 distinct gobo patterns, 7 vibrant colors plus white, semi-color effects, and strobe capabilities. The light supports DMX 512 control, sound-activated mode, automatic operation, and master/slave configurations, offering flexible control options for diverse lighting needs.
Please read this manual thoroughly before operating the device to ensure safe and correct usage and to maximize the product's lifespan.
2. Safety Instructions
- Electrical Safety: Ensure the power supply voltage matches the device's requirements (240 Volts). Always connect to a grounded outlet. Disconnect power before cleaning or servicing.
- Installation: Install the fixture in a well-ventilated area, away from heat sources. Ensure secure mounting using appropriate brackets and safety cables. Avoid direct exposure to rain or moisture.
- Operation: Do not look directly into the light source, as it can cause eye damage. Keep the device away from flammable materials. Operate within the specified temperature range.
- Maintenance: Refer to the maintenance section for proper cleaning and care. Only qualified personnel should perform repairs.
3. Product Overview
3.1 Components and Features
The UKing ZQ02006 is a compact and flexible moving head light, designed for ease of use and powerful performance.
Figure 1: Internal Components and Display
- Optical Lens: Projects clear and sharp light beams.
- Gobo Wheel: Features 8 distinct gobo patterns for varied projections.
- Color Wheel: Offers 7 colors plus white, enabling a wide spectrum of lighting effects.
- Cooling Fan & Heat Dissipation: Ensures optimal operating temperature and extends product life.
- LCD Function Display: Provides an interface for mode selection and settings adjustment.
- DMX In/Out: 3-pin XLR connectors for DMX 512 control.
- Power Connector: Standard power input.
- Sound Pickup: Integrated microphone for sound-activated mode.
Figure 2: Gobo and Color Wheels
Figure 3: Heat Dissipation and Connectors
3.2 Movement Capabilities
The ZQ02006 offers extensive movement for dynamic lighting effects:
- Pan (X-axis): 540° rotation.
- Tilt (Y-axis): 270° movement.
The speed of both pan and tilt movements can be controlled, allowing for precise and synchronized light shows.
Figure 4: Pan and Tilt Movement
4. Setup
4.1 Mounting
The moving head light can be mounted in various positions (e.g., truss, ceiling, floor) using its flexible bracket mount. Ensure the mounting surface or structure can safely support the weight of the fixture (2.51 kg) and any additional equipment. Always use a safety cable as a secondary attachment.
- Attach the mounting bracket securely to the fixture.
- Fasten the fixture to the desired location using appropriate clamps or screws.
- Always attach a safety cable to prevent accidental drops.
4.2 Connections
- Power: Connect the power cable to the power input on the fixture and then to a suitable grounded power outlet.
- DMX Control (Optional): For DMX operation, connect a DMX controller to the DMX IN port using a 3-pin XLR cable. If linking multiple fixtures, connect the DMX OUT of the first fixture to the DMX IN of the next, and so on. Terminate the last fixture in the chain with a DMX terminator.
5. Operating Modes
The UKing ZQ02006 offers several operating modes, selectable via the LCD function display on the unit.
5.1 DMX 512 Control Mode
This mode allows for professional control over all functions using a DMX controller. The fixture supports 9 or 11 DMX channels, providing granular control over pan, tilt, color, gobo, strobe, and other effects. Refer to the DMX Channel Chart (typically found in the full product manual) for specific channel assignments and values.
Figure 5: DMX Control Interface
5.2 Sound-Activated Mode
In this mode, the light reacts to ambient sound, creating dynamic effects synchronized with music. The sensitivity of the sound sensor can be adjusted via the menu to suit different audio environments.
Figure 6: Sound-Activated Feature
5.3 Automatic Mode
The fixture runs through a series of pre-programmed light shows and patterns automatically. This mode is ideal for quick setup without external control.
5.4 Master/Slave Mode
Connect multiple ZQ02006 fixtures together. Set one unit as the 'Master' and the others as 'Slave' units. The slave units will then mirror the master's movements and effects, creating a synchronized light show without a DMX controller.
Video 1: Demonstration of various light patterns and colors from the moving head light, showcasing its dynamic capabilities in a stage setting.
6. Maintenance
Regular maintenance ensures optimal performance and longevity of your moving head light.
- Cleaning: Periodically clean the optical lens and exterior casing with a soft, lint-free cloth. For stubborn dirt, use a mild glass cleaner. Ensure the device is powered off and unplugged before cleaning.
- Fan and Vents: Keep the cooling fan and ventilation openings clear of dust and debris to prevent overheating. Use compressed air to gently clear dust.
- Cable Inspection: Regularly check power and DMX cables for any signs of damage, fraying, or loose connections. Replace damaged cables immediately.
- Storage: When not in use, store the fixture in a dry, dust-free environment, preferably in its original packaging or a protective case.
7. Troubleshooting
If you encounter issues with your UKing ZQ02006, refer to the following common problems and solutions:
| Problem | Possible Cause | Solution |
|---|---|---|
| No power | Power cable disconnected; no power from outlet; fuse blown | Check power cable connection; test outlet; replace fuse if necessary |
| No light output | Light source failure; DMX signal issue (if in DMX mode); fixture in blackout mode | Check DMX connections and controller settings; verify fixture mode; contact support if light source is faulty |
| No movement (Pan/Tilt) | DMX signal issue; motor malfunction; fixture in static mode | Check DMX connections and controller settings; verify fixture mode; contact support if motor is faulty |
| Incorrect DMX response | Incorrect DMX address; DMX cable issue; DMX controller settings | Verify DMX address setting on fixture; check DMX cable integrity; ensure DMX controller is sending correct signals |
If the problem persists after attempting these solutions, please contact customer support.
8. Specifications
Here are the technical specifications for the UKing ZQ02006 50W LED Moving Head Light:
| Feature | Specification |
|---|---|
| Model Number | ZQ02006 |
| Light Source | 50W LED (Diode électroluminescente) |
| Power Consumption | 50 Watts |
| Voltage | 240 Volts |
| Control Modes | DMX 512 (9/11 Channels), Sound-Activated, Automatic, Master/Slave |
| Gobo Wheel | 8 Gobo Patterns + Open |
| Color Wheel | 7 Colors + White, Semi-Color Effects |
| Pan Angle | 540° |
| Tilt Angle | 270° |
| Dimensions (L x W x H) | 17.5 x 23 x 22.5 cm (6.9 x 9.1 x 8.9 inches) |
| Weight | 2.51 Kilograms (5.53 pounds) |
| Material | Aluminum, Polyvinyl Chloride (Shade) |
| Mounting Type | Bracket Mount |
| UPC / GTIN | 728458374022 |
Figure 7: Energy Label (Model ZQ02006EU). For more details, visit eprel.ec.europa.eu/qr/2332771
9. Warranty and Support
Your UKing ZQ02006 LED Moving Head Light comes with a free replacement policy within 30 days of purchase. For any questions or assistance, please do not hesitate to contact us. We commit to responding within 12 hours to ensure your satisfaction.
