Marrado V-A8-WOODEN Touch Control Table Lamp with Bluetooth Speaker

1. Introduction

Thank you for purchasing the Marrado V-A8-WOODEN Touch Control Table Lamp with Bluetooth Speaker. This versatile device combines ambient lighting with a portable audio experience. Please read this manual carefully to ensure proper use, maintenance, and to fully enjoy all features of your new lamp.

2. Safety Instructions

• Do not expose the device to extreme temperatures, direct sunlight, or high humidity.
• Keep the device away from water or other liquids.
• Do not attempt to disassemble, repair, or modify the device yourself. Contact customer support for assistance.
• Use only the provided USB charging cable or a certified equivalent.
• Keep out of reach of children.
• Dispose of the battery according to local regulations. Do not incinerate.

3. Package Contents

Please check the package for the following items:

• 1 x Marrado LED Touch Sensor Lamp
• 1 x USB Charging Cable
• 1 x User Manual
• 1 x Thank You Card

4. Product Overview and Features

The Marrado V-A8-WOODEN lamp offers a combination of lighting and audio functionalities:

• Touch-Activated Control: Easily adjust light settings with a simple touch.
• Integrated Bluetooth Speaker: Connect your device wirelessly to play music.
• Portable Design: Built-in 2000mAh rechargeable battery for wireless use.
• Dimmable Warm White Light: Four brightness levels for various needs.
• RGB Color Changing Mode: Automatic 256-color cycle or selection of a fixed color.
• Eye-Friendly 360° Light: Provides uniform and delicate illumination.
• Auto-Off Timer: Can be set to automatically turn off the light and music.

The lamp features an RGB color changing mode, supporting a full-color display of 16,000,000 colors, allowing you to set the mood with dynamic lighting.

Equipped with Bluetooth 4.2, the lamp functions as a wireless music player, allowing you to stream audio from your smartphone or other Bluetooth-enabled devices anytime, anywhere.

The built-in 2000mAh battery provides extended endurance. At the lowest brightness, the lamp can last approximately 200 hours. At middle brightness, it lasts about 36 hours, and music playback lasts about 4 hours.

Its portable design makes it suitable for various environments, providing both light and music for indoor and outdoor settings.

5. Setup

5.1 Charging the Lamp

1. Before first use, fully charge the lamp.
2. Connect the provided USB charging cable to the lamp's charging port and to a USB power adapter (not included) or a computer's USB port.
3. The charging indicator light will show the charging status (e.g., red for charging, green for fully charged).
4. A full charge typically takes a few hours.

6. Operating Instructions

The lamp features intuitive touch control for adjusting brightness levels, changing colors, switching Bluetooth audio, and setting the power-off duration.

6.1 Power On/Off

• To power on the lamp, touch and hold the top touch panel for approximately 2-3 seconds.
• To power off the lamp, touch and hold the top touch panel again for approximately 2-3 seconds.

6.2 Light Control

• Warm White Light: When the lamp is on, short touch the top panel to cycle through 4 levels of warm white brightness (low, medium, high, off).
• RGB Color Changing Mode: From warm white mode, long touch the top panel to switch to RGB color changing mode. The lamp will automatically cycle through 256 colors.
• Fixed RGB Color: While in RGB color changing mode, short touch the top panel to pause on the current color. Short touch again to resume the color cycle or select another color.
• RGB Brightness Adjustment: While in RGB mode (either cycling or fixed color), long touch the top panel to adjust the brightness of the current color.

6.3 Bluetooth Speaker Pairing

1. Ensure the lamp is powered on.
2. The lamp will automatically enter Bluetooth pairing mode, indicated by an audible prompt or flashing light.
3. On your smartphone or other Bluetooth-enabled device, enable Bluetooth and search for available devices.
4. Select "Marrado Lamp" (or similar name) from the list to pair.
5. Once paired, you will hear a confirmation sound, and you can now play music through the lamp's speaker.

6.4 Auto-Off Timer

The lamp includes a 2-hour auto-off timer, which can be set to automatically turn off both the light and music after a period ranging from 10 to 120 minutes. This is useful for falling asleep or conserving battery.

The lamp features an auto-off timer function. Refer to the specific instructions in the included quick start guide or product packaging for how to activate and set the timer duration (e.g., 10-120 minutes).

7. Maintenance

• Cleaning: Wipe the lamp with a soft, dry cloth. Do not use abrasive cleaners or immerse the lamp in water.
• Battery Care: To prolong battery life, avoid fully discharging the battery frequently. Charge the lamp regularly, even if not in use for extended periods.
• Storage: Store the lamp in a cool, dry place when not in use.

8. Troubleshooting

9. Specifications

10. Warranty and Support

Warranty: Marrado provides a LIFE-TIME warranty for this product, ensuring long-term satisfaction and support for manufacturing defects.

Customer Support: For any questions, issues, or technical assistance, please contact Marrado customer service. We offer 7x24 hours customer support to address your needs promptly.

Please refer to your purchase documentation or the Marrado website for specific contact details.
