Givi SR7055

GIVI Monolock Top Case Carrier

Model: SR7055 for SYM JET 14 125-200 (2017-2020)

Brand: GIVI

1. Introduction

This manual provides essential instructions for the proper installation, operation, and maintenance of your GIVI SR7055 Monolock Top Case Carrier. This specialized carrier is designed with two metallic supports to facilitate the mounting of GIVI Monokey and Monolock plates (plates are typically supplied with the top case, not the carrier). Its compact design ensures it integrates seamlessly with your SYM JET 14 125cc or 200cc scooter models from 2017 to 2020 without altering the vehicle's profile.

Please read this manual thoroughly before attempting installation or use to ensure safety and optimal performance.

2. Safety Information

  • Professional Installation Recommended: If you are unsure about any step of the installation process, it is highly recommended to seek assistance from a qualified mechanic or GIVI authorized dealer.
  • Check Fasteners Regularly: After initial installation and periodically thereafter, check all bolts, nuts, and fasteners to ensure they are securely tightened. Vibrations during riding can cause fasteners to loosen.
  • Weight Limit: Adhere strictly to the maximum load capacity specified for your GIVI top case and the scooter manufacturer's recommendations. Overloading can affect vehicle stability and handling.
  • Driving Dynamics: The addition of a top case and its contents can alter the scooter's center of gravity and aerodynamic characteristics. Exercise caution, especially at high speeds, in crosswinds, or when cornering.
  • Secure Top Case: Always ensure the top case is correctly and securely locked onto the carrier plate before riding.

3. Package Contents

Please verify that all components are present before beginning installation:

  • GIVI SR7055 Metallic Supports (2 pieces)
  • Mounting Hardware (bolts, washers, spacers, etc.)
  • Instruction Leaflet (this document)

Note: The Monolock or Monokey plate required for attaching a top case is typically included with the GIVI top case itself, not with this carrier kit.

4. Installation / Setup

The following steps outline the general procedure for installing the GIVI SR7055 carrier. Specific details may vary slightly; always refer to the included diagrams and your scooter's service manual if necessary.

  1. Prepare the Scooter: Ensure the scooter is parked on a stable, flat surface, preferably on its center stand. Turn off the engine and remove the key.
  2. Remove Existing Components (if applicable): Depending on your scooter's configuration, you may need to remove the rear grab handles or any existing luggage rack to access the mounting points.
  3. Position the Supports: Carefully place the GIVI metallic supports onto the designated mounting points on the rear of your SYM JET 14. These points are usually located near the rear passenger seat or fender.
  4. Attach Mounting Hardware: Using the provided bolts, washers, and spacers, loosely secure the metallic supports to the scooter's frame. Do not fully tighten at this stage.
  5. Mount the Monolock Plate: Once the supports are loosely in place, attach your GIVI Monolock plate (sold separately with the top case) to the metallic supports using the hardware provided with the plate. Ensure the plate is correctly oriented.
  6. Align and Tighten: Adjust the position of the supports and the plate to ensure proper alignment and a level surface. Once satisfied with the alignment, progressively tighten all bolts to the manufacturer's specified torque settings. Start with the bolts securing the supports to the scooter, then the bolts securing the plate to the supports.
  7. Final Check: Double-check all fasteners for tightness. Gently shake the installed carrier to ensure it is rigid and stable. Test the attachment mechanism of your Monolock top case to the newly installed plate.
GIVI SR7055 Monolock Top Case Carrier components

An image showing the GIVI SR7055 Monolock Top Case Carrier components, including the metal supports and mounting hardware, ready for installation.

5. Operating Instructions

Once the GIVI SR7055 carrier and Monolock plate are securely installed, operating your GIVI Monolock top case is straightforward:

  • Attaching the Top Case: Align the hooks on the front underside of your Monolock top case with the corresponding slots on the front of the Monolock plate. Push the top case down firmly until you hear a 'click' sound, indicating it is securely locked onto the plate. Always verify the lock by gently pulling up on the case.
  • Detaching the Top Case: Insert your key into the top case lock and turn it to the unlock position. While holding the key turned, press the release button (usually located near the lock mechanism). Lift the top case upwards and away from the plate.

6. Maintenance

  • Regular Inspection: Periodically inspect the carrier for any signs of wear, damage, or corrosion. Check all mounting points and welds.
  • Fastener Check: Re-check the tightness of all bolts and nuts every few months or after long rides, especially if riding on rough terrain.
  • Cleaning: Clean the metallic supports with a mild soap solution and water. Avoid abrasive cleaners or solvents that could damage the finish.

7. Troubleshooting

  • Carrier Feels Loose: If the carrier feels unstable or loose, immediately stop riding and check all mounting bolts. Tighten any loose fasteners according to the installation instructions. If the issue persists, inspect for damaged components or incorrect installation.
  • Top Case Not Locking Securely: Ensure the Monolock plate is correctly installed and not damaged. Check the locking mechanism on the top case for any obstructions or wear. Lubricate the lock if necessary.
  • Unusual Noise During Riding: Rattling or other unusual noises may indicate loose fasteners or improper installation. Stop and inspect the carrier and top case thoroughly. Ensure no components are vibrating against the scooter's bodywork.

8. Specifications

  • Model: SR7055
  • Compatibility: SYM JET 14 125cc and 200cc (Model Years 2017-2020)
  • Type: Monolock Top Case Carrier (also compatible with Monokey plates)
  • Material: Metallic supports
  • Weight: Approximately 2.02 kg (4.45 lbs)

9. Warranty and Support

GIVI products are manufactured to high-quality standards. For specific warranty information, please refer to the warranty card included with your purchase or visit the official GIVI website. Keep your proof of purchase for warranty claims.

For technical support, spare parts, or further assistance, please contact your local GIVI dealer or the GIVI customer service department through their official channels.

© GIVI. All rights reserved. Information in this manual is subject to change without notice.
