5 five simply smart FIVE-151188

5five Digital Kitchen Scale with Removable Tray

Model: FIVE-151188

1. Introduction

Thank you for choosing the 5five Digital Kitchen Scale. This manual provides essential information for the safe and efficient use of your new scale. Please read it thoroughly before first use and keep it for future reference.

This digital kitchen scale is designed for precise measurement of ingredients up to a maximum capacity of 5 kg, featuring a convenient removable tray for easy cleaning and versatile use.

2. Important Safety Information

  • Do not immerse the scale in water or other liquids.
  • Clean the scale with a damp cloth. Do not use abrasive cleaners.
  • Place the scale on a flat, stable surface for accurate measurements.
  • Do not overload the scale beyond its maximum capacity of 5 kg, as this may cause damage.
  • Keep the scale away from extreme temperatures and direct sunlight.
  • This appliance is for household use only.
  • Keep out of reach of children.

3. Package Contents

Please check that all items are present and in good condition:

  • 1 x 5five Digital Kitchen Scale
  • 1 x Removable Weighing Tray
  • 1 x User Manual (this document)
5five Digital Kitchen Scale with removable tray, top view

Image: The 5five Digital Kitchen Scale, showing the main unit and the clear removable weighing tray.

4. Setup

4.1 Battery Installation

The scale requires batteries (not included) for operation. Please check the battery compartment for the specific type required (e.g., AAA or CR2032) and follow these steps:

  1. Locate the battery compartment on the underside of the scale.
  2. Open the battery compartment cover.
  3. Insert the required batteries ensuring correct polarity (+/-).
  4. Close the battery compartment cover securely.

4.2 Placing the Scale

Place the scale on a hard, flat, and stable surface to ensure accurate readings. Avoid soft or uneven surfaces.

4.3 Attaching the Removable Tray

Gently place the clear removable weighing tray onto the scale's weighing platform. Ensure it is seated correctly and stably before use.

5. Operating Instructions

5.1 Turning On/Off

  • To turn on: Press the ON/OFF button (often integrated with the TARE button). The display will show "0" or "0.0".
  • To turn off: Press and hold the ON/OFF button for a few seconds, or the scale will automatically shut off after a period of inactivity to conserve battery life.

5.2 Unit Conversion

To change the unit of measurement (e.g., grams, ounces, pounds, milliliters):

  • Press the UNIT button. The display will cycle through available units.
  • Select your desired unit.

5.3 Tare Function

The Tare function allows you to weigh multiple ingredients in the same container or to subtract the weight of a container:

  1. Place an empty container (or the removable tray) on the scale. The display will show its weight.
  2. Press the TARE button. The display will reset to "0".
  3. Add your ingredient to the container. The display will show only the weight of the ingredient.
  4. Repeat the TARE function for additional ingredients.

5.4 Weighing Items

  1. Ensure the scale is on and displaying "0".
  2. Place the item directly onto the removable tray or in a container on the tray.
  3. Read the weight displayed on the screen.
Digital kitchen scale weighing brown sugar in a clear tray

Image: The 5five Digital Kitchen Scale in use, accurately weighing brown sugar in its removable tray.

6. Maintenance and Care

6.1 Cleaning

  • Wipe the scale body with a soft, damp cloth. Do not use chemical or abrasive cleaning agents.
  • The removable tray can be washed with warm soapy water. Ensure it is completely dry before placing it back on the scale.
  • Do not immerse the main unit of the scale in water.

6.2 Storage

Store the scale in a cool, dry place. If not in use for an extended period, it is recommended to remove the batteries to prevent leakage.

7. Troubleshooting

ProblemPossible CauseSolution
Scale does not turn on.Dead or incorrectly installed batteries.Check battery polarity or replace batteries.
Inaccurate readings.Scale on an uneven surface; overloaded; external vibrations.Place on a flat, stable surface. Do not exceed 5 kg. Avoid vibrations.
Display shows "Lo".Low battery power.Replace batteries.
Display shows "Err" or "O-Ld".Scale is overloaded.Remove items immediately. Do not exceed 5 kg.

8. Specifications

  • Model Number: FIVE-151188
  • Brand: 5 five simply smart
  • Maximum Capacity: 5 Kilograms
  • Measurement Precision: +/-0.5%
  • Material: Plastic
  • Color: White
  • Special Feature: Removable Tray
  • Product Weight: 300 g
  • Manufacturer: JJA
  • Country of Origin: China

9. Warranty and Customer Support

For warranty information or if you encounter any issues not covered in this manual, please contact 5five customer support. Refer to your purchase documentation for specific warranty terms and contact details.

You can often find support contact information on the official 5five website or through the retailer where you purchased the product.

© 2023 5 five simply smart. All rights reserved.
