1. Introduction
This manual provides essential information for the safe and effective use of your Den Hartog Ace Roto-Mold SP0020-LC 20 Gallon Sumped Rectangular Applicator Tank. Please read this manual thoroughly before installation, operation, or maintenance to ensure proper handling and longevity of the product.
The SP0020-LC is a 20-gallon rectangular tank designed for various liquid containment applications. It features a sumped bottom for efficient draining, translucent walls for easy level viewing, and is constructed from medium-density polyethylene with U.V. inhibitors for durability. It comes standard with a 3/4" FNPT polypropylene fitting with a Santoprene gasket and a 5" vented lid.
2. Safety Information
Always observe the following safety precautions to prevent injury or damage to the tank:
- Ensure the tank is placed on a flat, stable, and level surface capable of supporting the full weight of the tank and its contents. A 20-gallon tank filled with water weighs approximately 160 lbs (72.5 kg) plus the tank's own weight.
- Do not exceed the tank's maximum capacity of 20 gallons.
- Verify that the liquid being stored is compatible with medium-density polyethylene and does not exceed a specific gravity of 1.7. Incompatible liquids can cause tank degradation and failure.
- Always secure the vented lid properly to prevent spills and contamination, while allowing for necessary air exchange.
- Inspect the tank and all fittings regularly for any signs of damage, cracks, or leaks. Do not use a damaged tank.
- Wear appropriate personal protective equipment (PPE) when handling or filling the tank, especially if storing hazardous liquids.
- Keep the tank away from open flames, excessive heat, and sharp objects.
- Dispose of contents and the tank itself according to local environmental regulations.
3. Product Components
The Den Hartog Ace Roto-Mold SP0020-LC tank includes the following standard components:
- One (1) 20 Gallon Sumped Rectangular Applicator Tank (Model: SP0020-LC)
- One (1) 3/4" FNPT Polypropylene Fitting with Santoprene Gasket (pre-installed in sump)
- One (1) 5" Vented Lid (for top opening)
Image 1: Top-down view of the Den Hartog Ace Roto-Mold SP0020-LC 20 Gallon Sumped Rectangular Applicator Tank, showing the translucent walls and the black vented lid.
Image 2: Top view of the tank highlighting the 5-inch black vented lid, which allows for pressure equalization during filling and draining.
4. Setup and Installation
- Unpacking and Inspection: Carefully remove the tank from its packaging. Inspect the tank for any visible damage that may have occurred during shipping. Check that the lid and fitting are securely in place.
- Placement: Select a suitable location for the tank. The surface must be flat, level, and strong enough to support the tank's weight when full. Ensure adequate clearance around the tank for access, filling, and draining.
- Initial Cleaning: Before first use, it is recommended to rinse the interior of the tank with clean water to remove any manufacturing residues. Ensure the rinse water is properly drained and disposed of.
- Fitting Connection: The tank comes with a 3/4" FNPT polypropylene fitting with a Santoprene gasket pre-installed in the sump. If connecting hoses or other plumbing, ensure all connections are tight and leak-free. Use appropriate thread sealant if necessary.
Image 3: Close-up view of the 3/4" FNPT polypropylene fitting located in the tank's sump, designed for efficient draining.
Image 4: Angled view of the tank, providing a clearer perspective of the sump design and the integrated fitting for drainage.
5. Operating Instructions
- Filling the Tank:
- Ensure the tank is securely positioned and all outlet fittings are closed or properly connected.
- Unscrew the 5" vented lid from the top opening.
- Carefully pour or pump the desired liquid into the tank. Do not overfill.
- Monitor the liquid level using the translucent tank walls and integrated gallon indicators.
- Once filling is complete, securely re-attach the vented lid.
- Monitoring Liquid Levels: The tank's translucent walls allow for visual inspection of the liquid level. Gallon indicators are molded into the tank surface to provide approximate volume readings.
- Draining the Tank:
- Connect a hose or appropriate plumbing to the 3/4" FNPT fitting in the sump.
- Open the valve or connection to allow the liquid to drain. The sumped design facilitates near-complete drainage.
- Ensure proper containment and disposal of the drained liquid.
6. Maintenance and Care
- Regular Cleaning: Periodically clean the interior and exterior of the tank. For interior cleaning, rinse with clean water. For stubborn residues, use a mild detergent compatible with polyethylene and the stored liquid, followed by thorough rinsing.
- Inspection: Regularly inspect the tank for any signs of wear, cracks, or damage, especially around fittings and seams. Check the lid and gasket for proper sealing. Replace any damaged components immediately.
- Gasket Maintenance: The Santoprene gasket on the fitting should be inspected for deterioration. If it appears cracked or hardened, it should be replaced to prevent leaks.
- Storage: When not in use, store the tank in a cool, dry place, away from direct sunlight and extreme temperatures. If storing outdoors, ensure the lid is securely fastened to prevent debris from entering.
7. Troubleshooting
| Problem | Possible Cause | Solution |
|---|---|---|
| Liquid Leakage | Loose fitting, damaged gasket, crack in tank wall. | Tighten fitting. Inspect and replace gasket if damaged. If tank wall is cracked, the tank may need replacement. |
| Lid not sealing properly | Lid not tightened, debris on sealing surface, damaged lid or tank opening. | Ensure lid is fully tightened. Clean sealing surfaces. Inspect lid and tank opening for damage; replace if necessary. |
| Difficulty viewing liquid level | Exterior dirt/grime, interior residue buildup. | Clean the exterior of the tank. Perform interior cleaning if residue is present. |
| Tank deformation | Overfilling, incompatible liquid, exposure to extreme temperatures, improper support. | Do not overfill. Ensure liquid compatibility. Store within recommended temperature ranges. Provide adequate, flat support. |
8. Specifications
| Model Number | SP0020-LC |
| Brand | Den Hartog (Ace Roto-Mold) |
| Capacity | 20 Gallons |
| Dimensions (L x W x H) | Approximately 28 inches x 14 inches x 12 inches |
| Nominal Wall Thickness | 0.175 inches |
| Material | Medium-Density Polyethylene (MDPE) with U.V. Inhibitors |
| Fitting | 3/4" FNPT Polypropylene with Santoprene Gasket |
| Lid | 5" Vented Lid |
| Empty Weight | 13 lbs |
| Specific Gravity Rating | Up to 1.7 |
| UPC | 768570801501 |
Image 5: Side view of the tank showing the product label, including model number SP0020-LC and NSF certification for quality assurance.
Image 6: Detailed view of the product label, displaying the model number SP0020-LC, UPC, and other manufacturing details.
9. Warranty Information
Specific warranty details for the Den Hartog Ace Roto-Mold SP0020-LC tank are not provided in this manual. For information regarding product warranty, please contact the original seller or Den Hartog directly through their official website or customer service channels. Please retain your proof of purchase for any warranty claims.
10. Customer Support
If you have any questions, require technical assistance, or need to report an issue with your Den Hartog Ace Roto-Mold SP0020-LC tank, please contact Den Hartog customer support. You can typically find contact information on the manufacturer's official website or through the retailer from whom you purchased the product.
For more information, you may visit the Den Hartog Store on Amazon.
