SVAVO Automatic Soap Dispenser (Model V-473) User Manual

Introduction

This SVAVO Automatic Soap Dispenser provides a touchless and hygienic solution for dispensing liquid soap. Featuring an infrared sensor and adjustable volume control, it is suitable for various environments such as homes, schools, and kitchens.

Product Features

• Touchless Operation: Equipped with an infrared sensor for hygienic, automatic soap dispensing.
• Adjustable Volume Control: Offers 3 distinct output levels (1.0ml, 2.0ml, 3.0ml) to suit different needs.
• Top-Loaded Battery Compartment: Designed to protect 4 AAA alkaline batteries (not included) from water damage.
• Anti-Leakage Design: Features a new version silicone nozzle to prevent drips and waste.
• Large Capacity: Holds 350ml (12oz) of liquid soap, reducing refill frequency.
• Versatile Use: Compatible with various liquid hand soaps and dish soaps.

Figure 1: Product Parts Diagram

Figure 2: Infrared Sensor for Touchless Operation

Package Contents

• 1 x SVAVO Automatic Soap Dispenser
• 1 x User Manual

Setup

1. Battery Installation

1. Locate the battery compartment on the top of the dispenser.
2. Open the battery cap.
3. Insert 4 new AAA alkaline batteries, ensuring correct polarity.
4. Close the battery cap securely.

Figure 3: Top-Loaded Battery Compartment

2. Filling the Soap Dispenser

1. Unscrew the bottom liquid bottle from the main unit.
2. Pour liquid soap into the bottle. Do not overfill.
3. Securely screw the liquid bottle back onto the main unit.

Figure 4: Filling the Soap Dispenser

3. Setup Video Guide

Watch this video for a visual guide on battery installation and soap filling:

Operation

1. Power On/Off

Press the power button located on the top of the dispenser to turn it on. An indicator light will illuminate, signaling that the dispenser is ready for use. Press the button again to turn it off.

2. Dispensing Soap

Place your hand under the infrared sensor. The dispenser will automatically release a measured amount of soap. For first-time use or after refilling, it may require several activations for the soap to prime and dispense consistently.

3. Adjusting Soap Volume

The dispenser offers three output levels. To adjust the volume, press the power button repeatedly to cycle through the settings:

• Level 1 (1.0ml): Ideal for children or light hand washing.
• Level 2 (2.0ml): Suitable for adults and general hand washing.
• Level 3 (3.0ml): Recommended for washing dishes or when more soap is needed.

Figure 5: Adjustable Soap Volume Settings

Maintenance

1. Cleaning

Clean the exterior of the dispenser with a soft, damp cloth. Do not immerse the dispenser in water, as this can damage the electronic components. The anti-leakage silicone nozzle is designed to minimize drips and keep the unit clean.

2. Refilling

When the soap level is low, unscrew the bottom liquid bottle and refill it with your preferred liquid soap. The large opening makes refilling easy and mess-free.

Figure 6: Large Opening for Easy Refilling

Troubleshooting

• Dispenser not working:
  • Ensure 4 AAA alkaline batteries are correctly installed in the top compartment.
  • Verify the dispenser is powered on by pressing the power button.
  • If it's the first use or after refilling, activate the sensor several times to prime the pump and draw soap up the tube.
  • Check if the soap reservoir is empty.
• Soap not dispensing:
  • Ensure the soap tube is properly positioned inside the liquid bottle.
  • If using very thick soap, consider diluting it slightly with water to improve flow.
• Leakage:
  • Ensure the bottom liquid bottle is securely screwed onto the main unit.
  • The dispenser features an anti-leakage silicone nozzle designed to prevent drips.

Specifications

Warranty & Support

The SVAVO Automatic Soap Dispenser comes with a 2-year warranty, ensuring quality and reliability. For any questions, technical assistance, or warranty claims, please refer to the official SVAVO website or contact customer service through the provided channels.
