Product Overview
The BQLZR 285805 Water Inlet Valve is a replacement component designed for various washing machine models. This valve controls the flow of hot and cold water into the washer tub, ensuring proper filling during wash cycles. It is engineered to meet original equipment manufacturer (OEM) standards for reliable performance.
Brand: BQLZR
Model: 285805
Voltage: AC110V-AC120V
Frequency: 50-60Hz
Material: Metal, Plastic
This part replaces multiple part numbers including 21026, 285805, 285805VP, 292197, 3349451, 3354565, 3360387, 3360388, 3360389, 3360391, 3360392, 3429537, 358992, 370067, 388328, 3952163, 3952164, 3955673, 8228, 868761, 99989697, AP3094541, W10110517, PS334646. It is compatible with washing machines from brands such as Whirlpool, Kenmore, KitchenAid, Roper, Estate, Inglis, and Crosley.
Product Features
- Universal Compatibility: Designed for a wide range of clothes washer models.
- Easy Installation: Engineered for straightforward installation and handling.
- Durable Construction: Made from metal and plastic for longevity.
- OEM Standard: Meets or exceeds original equipment manufacturer specifications.
Symptoms Addressed
A faulty water inlet valve can cause several issues with your washing machine. Replacing the valve can resolve the following common symptoms:
- Washer does not stop filling with water.
- No hot or cold water entering the washer.
- Washer will not fill with water.
- Water leaks from the valve area.
Video: Common washer issues including water valve problems.
Installation Instructions
Safety First: Before beginning any repair, always disconnect the washing machine from its power source and turn off the water supply to prevent electric shock or water damage.
Step 1: Access the Water Inlet Valve
Depending on your washing machine model, you may need to remove the back panel or top panel to access the water inlet valve. Refer to your washer's specific service manual for detailed access instructions.
Image: The BQLZR 285805 Water Inlet Valve shown in a laundry room setting, indicating its purpose as a washing machine component.
Step 2: Disconnect Old Valve and Hoses
Once the valve is accessible, disconnect the electrical wires connected to the solenoids. Note which wire goes to the hot water solenoid and which goes to the cold water solenoid. Then, disconnect the hot and cold water inlet hoses from the valve. Be prepared for some residual water to drain.
Image: Front view of the BQLZR 285805 Water Inlet Valve, highlighting the two threaded inlets with integrated filters and the mounting bracket.
Image: Angled view of the BQLZR 285805 Water Inlet Valve, showing the two solenoids and their electrical terminals.
Image: A close-up view of the mesh filters inside the water inlet ports of the valve, designed to prevent debris from entering the washing machine.
Step 3: Remove the Old Valve
Unscrew any mounting screws or clips securing the old water inlet valve to the washing machine chassis. Carefully remove the old valve.
Step 4: Install the New Valve
Position the new BQLZR 285805 Water Inlet Valve in the same location as the old one. Secure it with the mounting screws or clips. Connect the hot and cold water inlet hoses to the corresponding ports on the new valve. Ensure connections are tight to prevent leaks. Reconnect the electrical wires to the solenoids, ensuring correct polarity if specified (typically hot to hot, cold to cold).
Video: Overview of the 285805 Washer Water Inlet Valve and its application in a washing machine.
Video: Detailed view of the 285805 Washer Water Inlet Valve with mounting bracket, showing its components and design.
Step 5: Test the Washer
Restore the water supply and power to the washing machine. Run a short cycle to check for proper water filling and to ensure there are no leaks from the new valve or hose connections.
Specifications
| Attribute | Value |
|---|---|
| Manufacturer | BQLZR |
| Part Number | M4180528062 |
| Item Model Number | M4180528062 |
| Size (Length) | 9.5 cm / 3.74 inches |
| Material | Metal, Plastic |
| Item Weight | 100 g |
| Inlet Connection Size | 1.88 Inches |
| Inlet Connection Type | FNPT |
| Outlet Connection Type | FNPT |
| Number of Ports | 1 |
| Outlet Connection Size | 1.88 Inches |
| UPC | 192031168559 |
Image: Technical drawing showing the dimensions of the BQLZR 285805 Water Inlet Valve, including length, height, and inlet diameters.
Maintenance
To ensure the longevity and proper functioning of your water inlet valve and washing machine:
- Regular Inspection: Periodically check the valve and hose connections for any signs of leaks, corrosion, or wear.
- Filter Cleaning: The inlet ports of the valve contain mesh filters. If water flow is reduced, these filters may be clogged and require cleaning. Turn off water supply and power before removing and cleaning the filters.
- Hose Condition: Inspect the water inlet hoses for cracks, bulges, or leaks. Replace worn hoses promptly.
Troubleshooting
If you encounter issues after installing the new water inlet valve, consider the following:
- No Water Filling:
- Ensure water supply valves are fully open.
- Check electrical connections to the valve solenoids.
- Inspect inlet filters for clogs.
- Continuous Filling (Won't Stop):
- This often indicates a faulty water level switch or a stuck valve. If the new valve is installed correctly, check the water level switch.
- Leaks:
- Tighten all hose connections.
- Inspect hoses for damage.
- Ensure the valve is properly seated and mounted.
