1. Product Overview
The Pyle PDJLT50 is a multi-color DJ LED stage light system designed for professional DJ, dance show, and studio performances. It features RGBW color LED bulbs, flashing disco strobe effects, beat sync motion, and DMX control capabilities. This high-powered, energy-efficient light provides dynamic lighting for various events.
Figure 1: Pyle PDJLT50 LED Stage Light. This image shows the main unit with its seven LED bulbs illuminated in blue, highlighting the control panel at the base.
2. Key Features
- Multi-Color Lighting System: Features Red, Green, Blue, and White (RGBW) LED illumination for a full spectrum of colors.
- High-Powered Electronic Plug-in Design: Ensures reliable and consistent performance.
- Motorized Automatic Mode Movement: Offers configurable horizontal (540°) and vertical (270°) light alignment for dynamic effects.
- Digital LCD Display with Button Controls: Provides easy access to settings and modes.
- Electronic Strobe Mode: Includes pulsing and randomized light patterns with adjustable speed.
- Adjustable & Configurable Lighting FX Effects: Allows customization of light patterns and intensity.
- DMX Control: Supports Digital Multiplex (DMX) Standard with 9/14-channel options for professional integration.
- Beat Sync Motion Effect: Built-in microphone detects music BPM to synchronize light patterns.
Figure 2: LED Illumination Light Source. This image illustrates the light's capability to produce vibrant Red, Green, White, and Blue colors from its high-powered LED bulbs.
Figure 3: Motorized Automatic Mode Movement. This image demonstrates the light's ability to rotate 540 degrees horizontally and tilt 270 degrees vertically, indicating its dynamic range of motion.
3. What's in the Box
- Pyle PDJLT50 LED Stage Lighting System
- Power Cable
4. Setup Instructions
- Unpacking: Carefully remove the PDJLT50 unit and its accessories from the packaging. Inspect for any signs of damage.
- Placement: Place the unit on a stable, flat surface or mount it securely using appropriate hardware (not included) to a truss or ceiling. Ensure adequate ventilation around the unit.
- Power Connection: Connect the provided power cable to the power input on the rear of the unit and then to a compatible 110/240V, 50/60Hz power outlet.
- DMX Connection (Optional): For DMX control, connect a standard DMX cable from your DMX controller to the DMX IN port on the PDJLT50. If linking multiple units, connect from the DMX OUT of the first unit to the DMX IN of the next.
Figure 4: Rear Panel and Dimensions. This image provides a rear view of the light, showing the power input, DMX IN/OUT ports, and key dimensions (6.5'' x 6.7'' x 9.7'').
5. Operating Instructions
5.1. Control Panel Overview
The control panel features a digital LCD display and four buttons for navigation and setting adjustments:
- MODE/ESC: Press to cycle through main menus or exit current setting.
- UP: Increase values or navigate up through menu options.
- DOWN: Decrease values or navigate down through menu options.
- ENTER: Confirm selection or enter a submenu.
5.2. Operating Modes
The PDJLT50 offers several operating modes:
- Automatic Mode: The unit performs pre-programmed light shows with motorized movement and color changes. Use the control panel to select different automatic programs or adjust speed.
- Sound-Activated Mode (Beat Sync): The built-in microphone detects audio signals and synchronizes light patterns and movement to the beat of the music.
- DMX Mode: For professional control, connect the unit to a DMX controller. Refer to the DMX Channel Chart in Section 7 for specific channel functions.
- Master/Slave Mode: Link multiple PDJLT50 units. Set one unit as "Master" and others as "Slave" to synchronize their operation.
5.3. Adjusting Settings
Use the UP/DOWN buttons to adjust parameters such as:
- Dimmer: Adjust light intensity (0-100%).
- Strobe Speed: Control the speed of the flashing effect.
- Motor Speed: Adjust the speed of the motorized pan and tilt movements.
- DMX Channel Selection: Choose between 9-channel or 14-channel DMX modes.
Figure 5: Product in Use (DJ Performance). This image shows the Pyle PDJLT50 light actively projecting a blue beam during a DJ performance, demonstrating its application in a professional setting.
Figure 6: Product in Use (Party Scene). This image depicts the Pyle PDJLT50 light illuminating a party scene with green and red lights, showcasing its ability to enhance social gatherings.
6. Maintenance
- Cleaning: Regularly clean the exterior of the unit with a soft, dry cloth. Do not use abrasive cleaners or solvents. Ensure the lens is free of dust and smudges for optimal light output.
- Ventilation: Ensure the cooling fan and ventilation openings are clear of obstructions to prevent overheating.
- Storage: When not in use, store the unit in a cool, dry place, away from direct sunlight and extreme temperatures.
- Power Disconnection: Always disconnect the power cable before performing any cleaning or maintenance.
7. Troubleshooting
| Problem | Possible Cause | Solution |
|---|---|---|
| No Power | Power cable not connected; Power outlet faulty; Unit fuse blown. | Check power cable connection; Test power outlet; Replace fuse (T6.3). |
| No Light Output | Dimmer setting too low; Unit in standby mode; LED failure. | Increase dimmer level; Check operating mode; Contact support if LEDs are faulty. |
| No Movement | Motor speed setting too low; Unit in static mode; Motor malfunction. | Increase motor speed; Select an automatic or DMX mode with movement; Contact support. |
| DMX Control Issues | Incorrect DMX address; Faulty DMX cable; DMX controller issue. | Verify DMX address and channel mode; Check DMX cable integrity; Test with another DMX controller. |
| Overheating | Blocked ventilation; Prolonged use in high ambient temperature. | Ensure clear ventilation; Operate in a well-ventilated area; Allow unit to cool down. |
8. Technical Specifications
- Model: PDJLT50
- Light Source Power: 100 Watt
- Bulb Type: (7) Focused FX 4-in-1 x 10W, RGBW LEDs
- Connector Type: Digital Multiplex (DMX) Standard
- DMX Channels: 9/14-Channel selectable
- Dimmer Adjustment Levels: 1-255 (0-100%)
- Horizontal / Vertical Alignment Levels: 1-255
- Motor Speed Adjustment Levels: 1-255
- Power Cable Length: 3.94 ft.
- Fuse: T6.3
- Voltage Power: 110/240V, 50/60Hz
- Unit Dimensions (L x W x H): 6.5'' x 6.7'' x 9.7'' -inches
- Item Weight: 6.62 lbs
- Material: Plastic
- Color: Black
9. Warranty & Support
For detailed warranty information and customer support, please refer to the warranty card included with your product or visit the official Pyle website. Keep your purchase receipt as proof of purchase for any warranty claims.
For technical assistance or service inquiries, please contact Pyle customer support directly.
