Mobiclinic Hercules Rollator User Manual

1. Introduction

Thank you for choosing the Mobiclinic Hercules Rollator. This manual provides essential information for the safe and effective use, assembly, maintenance, and troubleshooting of your new mobility aid. Please read this manual thoroughly before using the rollator and keep it for future reference.

The Mobiclinic Hercules Rollator is designed to provide stability and support for individuals with mobility challenges, both indoors and outdoors. It features a lightweight aluminum frame, ergonomic handles, a comfortable seat with a backrest, and a convenient storage basket.

Figure 1: The Mobiclinic Hercules Rollator, a blue four-wheeled walker with a black seat, backrest, and storage basket.

2. Safety Information

• Always ensure all locking mechanisms are engaged before using the rollator.
• Do not exceed the maximum weight capacity of 100 kg (220 lbs).
• Regularly check the brakes for proper function. Engage the parking brakes when sitting or standing still.
• Ensure all four wheels are on a stable, level surface before sitting on the seat.
• Do not use the rollator on escalators, stairs, or uneven terrain that could cause instability.
• Keep hands and fingers clear of moving parts when folding or unfolding the rollator.
• Consult a healthcare professional to ensure this device is suitable for your specific mobility needs.

3. Package Contents

Upon opening the package, please verify that all components are present and undamaged:

• Mobiclinic Hercules Rollator frame with four wheels
• Padded seat
• Padded backrest
• Under-seat storage basket
• Instruction Manual (this document)

If any parts are missing or damaged, please contact Mobiclinic customer support immediately.

4. Setup and Assembly

The Mobiclinic Hercules Rollator comes largely pre-assembled. Follow these steps for initial setup and adjustment:

4.1 Unfolding the Rollator

1. Place the folded rollator on a flat surface.
2. Gently pull the side frames outwards until the rollator is fully open and the seat clicks into place.
3. Ensure the seat is securely locked before use.

Figure 2: The rollator can be easily unfolded for use and folded for compact storage and transport. The image shows a sequence of folding steps and the rollator stored in a car trunk and a closet.

4.2 Adjusting Handle Height

The handle height is adjustable to suit individual user needs, ensuring optimal comfort and posture.

1. Locate the height adjustment pins on the rollator's legs, near the handles.
2. Press the pin and slide the handle tube up or down to the desired height.
3. Ensure the pin fully re-engages in one of the adjustment holes.
4. Repeat for the other handle, ensuring both handles are at the same height.

Figure 3: The rollator's handles are adjustable from 83 cm to 101 cm to accommodate users of various heights, including taller individuals up to 1.90m.

Figure 4: Detailed view of the height adjustment points on the front and rear legs, and the handles, allowing for personalized height settings.

5. Operating Instructions

5.1 Walking with the Rollator

To use the rollator for walking, stand behind it with your hands on the ergonomic handles. Push the rollator forward a short distance, then step forward with one foot, followed by the other. Maintain a comfortable, upright posture. The solid PVC wheels with reflective strips provide smooth movement and enhanced visibility.

Figure 5: An elderly woman confidently walking outdoors with the Mobiclinic Hercules Rollator, highlighting its durable, puncture-proof 19.5 cm wheels and comfortable padded seat and backrest.

5.2 Using the Brakes

The Mobiclinic Hercules Rollator is equipped with manual brakes for safety and control.

• To slow down or stop: Squeeze the brake levers located on the handles towards you.
• To engage parking brakes: Push the brake levers down until they lock into place. This will prevent the rollator from moving, providing stability when sitting or standing.
• To release parking brakes: Pull the brake levers up until they disengage.

Figure 6: The ergonomic handle provides better movement control, improved maneuverability, and adapts to the hand's shape. It features a dual safety system to fully immobilize the walker, with a push-down action to engage the parking brake.

5.3 Using the Seat and Basket

The rollator features a comfortable padded seat and backrest for resting, and a convenient storage basket.

• To sit: Ensure the parking brakes are fully engaged. Turn around and slowly lower yourself onto the seat. Use the handles for support if needed.
• Storage Basket: The front-mounted basket is ideal for carrying personal items, groceries, or other essentials. It also includes a support for a cane or umbrella.

Figure 7: The rollator's under-seat basket provides secure storage for personal belongings, and includes a dedicated holder for a cane or umbrella.

6. Maintenance and Care

• Cleaning: Wipe down the frame, seat, and handles regularly with a damp cloth and mild detergent. Avoid abrasive cleaners.
• Inspection: Periodically check all screws, bolts, and fasteners to ensure they are tight. Inspect the wheels for wear and tear, and ensure they rotate freely. Check brake cables for fraying or damage.
• Storage: When not in use, store the rollator in a dry place, away from direct sunlight and extreme temperatures. The foldable design allows for compact storage.

7. Troubleshooting

If you encounter issues not listed here or if solutions do not resolve the problem, please contact Mobiclinic customer support.

8. Specifications

Figure 8: Comprehensive dimensions of the Mobiclinic Hercules Rollator, including height, width, length, and supported weight (100 kg), and total weight (6.7 kg).

Figure 9: A technical specifications table for the Hercules Rollator, detailing color, material, wheel type and size, brake type, seat dimensions, backrest dimensions, weight, maximum supported weight, total length, total width, adjustable total height, and folded dimensions.

9. Warranty and Support

Mobiclinic S.L. is a leading European company specializing in clinical and hospital furniture, daily support tools, and orthopedics since 1985. We are committed to providing high-quality products and customer satisfaction.

Figure 10: Mobiclinic, a trusted European brand, highlights its achievements including being awarded by His Majesty King Felipe VI of Spain, over 4 million products sold, and over 1 million satisfied customers.

For detailed warranty information, product registration, or technical support, please visit the official Mobiclinic website or contact their customer service department. Contact details can typically be found on the Mobiclinic brand store page or on the product packaging.

You can visit the Mobiclinic store on Amazon for more information: Mobiclinic Amazon Store
