Introduction
This manual provides detailed instructions for the safe installation, operation, and maintenance of your Troy Lighting B5803 LED Bath Fixture. Please read all instructions carefully before beginning installation and retain this manual for future reference. This modern vanity light features a hand-worked iron frame with a Gold Leaf finish and includes six G9 LED bulbs.
Important Safety Information: This product is intended for indoor use only. Installation should be performed by a qualified electrician to ensure proper wiring and safety. Always turn off the main power supply at the circuit breaker before installation or maintenance.
Proposition 65 Warning: This product may contain chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. Please check your local laws before purchasing this product.
Setup and Installation
Professional installation by a licensed electrician is highly recommended.
Included Components:
- Troy Lighting B5803 Fixture (1 unit)
- 4-watt G9 LED bulbs (6 units)
- Mounting hardware (typically included, specific items may vary)
Installation Steps (General Guidelines):
- Safety First: Turn off power at the circuit breaker before starting installation.
- Unpack: Carefully unpack all components and inspect for any damage.
- Mounting Bracket: Secure the mounting bracket to the junction box in the wall using the provided screws. Ensure it is firmly attached.
- Wiring: Connect the fixture's wires to the corresponding household wires (black to black, white to white, ground to ground) using wire connectors. Ensure all connections are secure.
- Secure Fixture: Attach the fixture body to the mounting bracket, ensuring all wires are tucked safely inside the junction box. Secure with screws or nuts as per design.
- Install Bulbs: Carefully insert the six G9 LED bulbs into their sockets.
- Restore Power: Once installation is complete and all connections are secure, restore power at the circuit breaker.
Refer to the detailed wiring diagram and specific hardware instructions provided in the packaging for precise installation steps.
Image 1: The Troy Lighting B5803 LED Bath Fixture in Gold Leaf. This image illustrates the overall design and the arrangement of the six light sources.
Operating Instructions
The Troy Lighting B5803 fixture operates via a standard wall toggle switch (not included with the fixture). Once installed and wired correctly, the fixture will turn on and off by toggling the connected wall switch.
- Light Source: The fixture uses six 4-watt G9 LED bulbs.
- Brightness: Provides a total light output of 2160 lumens.
- Color Temperature: Emits a warm white light at 3000 Kelvin.
- Lighting Method: Designed for uplight illumination.
Maintenance
Regular maintenance ensures the longevity and optimal performance of your fixture.
Cleaning:
- Always turn off power to the fixture at the circuit breaker before cleaning.
- Use a soft, dry, or slightly damp cloth to wipe down the metal and glass surfaces.
- Avoid abrasive cleaners, solvents, or polishes, as these can damage the finish.
- Do not spray cleaner directly onto the fixture.
Bulb Replacement:
- Ensure power is off at the circuit breaker and the fixture has cooled down before attempting to replace bulbs.
- The fixture uses G9 LED bulbs. When replacing, ensure the new bulbs match the wattage and base type (G9) to maintain performance and safety.
- Gently pull out the old G9 bulb and push in the new one. Do not twist.
Troubleshooting
If you experience issues with your fixture, consult the following common problems and solutions. For complex electrical issues, contact a qualified electrician.
| Problem | Possible Cause | Solution |
|---|---|---|
| Fixture does not light up. |
|
|
| Lights flicker or are dim. |
|
|
Specifications
| Brand | Troy Lighting |
| Model Number | B5803 |
| Fixture Type | Bathroom Vanity Light |
| Finish | Gold Leaf |
| Material | Hand-worked Iron, Glass (Shade) |
| Dimensions (L x W x H) | 20" x 20" x 7" |
| Item Weight | 16 Pounds |
| Number of Lights | 6 |
| Light Source Type | LED |
| Bulb Base | G9 |
| Wattage (per bulb) | 4 Watts |
| Total Brightness | 2160 Lumens |
| Color Temperature | 3000 Kelvin (Warm White) |
| Voltage | 120 Volts |
| Power Source | Corded Electric |
| Mounting Type | Protruding |
| Certification | UL Listed |
| Usage | Indoor use only |
Warranty Information
This Troy Lighting B5803 fixture is covered by a 1-year limited manufacturer warranty from the date of purchase. This warranty covers defects in materials and workmanship under normal use. It does not cover damage resulting from improper installation, accident, misuse, abuse, or unauthorized modifications.
Please retain your proof of purchase for warranty claims.
Customer Support
For technical assistance, missing parts, or warranty inquiries, please contact Troy Lighting customer service. Refer to the official Troy Lighting website or your purchase documentation for the most current contact information.
Online Resources: For additional product information and support, visit the official Troy Lighting Store on Amazon or the manufacturer's website.
