BOUDECH Ridelock Motorcycle Stand Lift User Manual

Product Overview

The BOUDECH Ridelock Motorcycle Stand Lift is designed to provide stable support for your motorcycle, facilitating maintenance tasks and offering a secure storage solution. This combo stand includes both front wheel fork and rear U/L fork swingarm spool stands, capable of supporting motorcycles up to 850 lbs. Constructed from durable powder-coated stainless steel, it offers adjustable width for compatibility with various motorcycle types.

Key Features:

• Durable powder-coated stainless steel construction ensures longevity and resistance to corrosion.
• Prevents tire flattening during long-term storage, preserving tire integrity.
• Facilitates various maintenance tasks such as chain adjustment, brake pad changes, tire changes, and oil changes.
• Adjustable width allows for easy adaptation to multiple motorcycle types and sizes.
• Equipped with smooth-rolling wheels for effortless transport and positioning of the stands.

Image: The BOUDECH Ridelock combo motorcycle stand set, featuring both front and rear stands.

1. Setup and Assembly

1.1 Unpacking

Carefully remove all components from the packaging. Verify that all parts are present. Inspect for any shipping damage before proceeding with assembly.

1.2 Component Identification

Identify the front stand, rear stand, and various adapters (U-fork, L-fork, spool pins). The stands are equipped with wheels for mobility. Familiarize yourself with each part before assembly.

Image: Both front and rear stands, showcasing the different adapter types for various motorcycle configurations.

1.3 Attaching Adapters

For the rear stand, choose between the U-fork adapters (designed for motorcycles with swingarm spools) or L-fork adapters (for flat swingarms). Insert the chosen adapters into the stand's arms and secure them firmly. For the front stand, attach the fork lift adapters, ensuring they are securely fastened.

Image: Detailed view of the U-fork adapter, used with motorcycle swingarm spools.

Image: Detailed view of the L-fork adapter, suitable for flat swingarms.

1.4 Adjusting Width

Adjust the width of both the front and rear stands to precisely match your motorcycle's swingarm or front fork width. Ensure a snug fit without excessive pressure or looseness. Secure the adjustment mechanisms firmly to prevent movement during use.

Image: Diagram showing key dimensions of the rear stand with U-fork adapters, including adjustable width.

Image: Diagram showing key dimensions of the front stand with L-fork adapters, including adjustable width.

2. Operating Instructions

2.1 Safety Precautions

• Always ensure the motorcycle is on a flat, stable, and level surface before attempting to lift.
• Engage the motorcycle's side stand or center stand (if equipped) before positioning the stands.
• Ensure the motorcycle is in neutral gear and the engine is off.
• Never attempt to lift a motorcycle that exceeds the stand's maximum weight capacity of 850 lbs.
• Always have a second person assist when lifting the motorcycle for the first time or if you are unsure about the process.
• Do not sit on the motorcycle while it is supported by the stands.

2.2 Lifting the Rear Wheel

1. Position the rear stand behind the motorcycle's rear wheel.
2. Align the stand's adapters with the motorcycle's swingarm spools or flat swingarm sections. Ensure the adapters make full and even contact.
3. Ensure both sides of the stand are evenly positioned and making firm contact with the motorcycle's swingarm.
4. Firmly and steadily press down on the stand's lever arm until the rear wheel lifts completely off the ground.
5. Verify the motorcycle is stable and securely supported on the stand before proceeding.

2.3 Lifting the Front Wheel

1. Once the rear wheel is securely lifted and the motorcycle is stable, position the front stand under the motorcycle's front forks.
2. Align the stand's fork lift adapters with the bottom of the front forks, ensuring they are centered and making even contact.
3. Ensure both sides of the stand are evenly positioned and making firm contact with the front forks.
4. Firmly and steadily press down on the stand's lever arm until the front wheel lifts completely off the ground.
5. Verify the motorcycle is stable and securely supported on both the front and rear stands.

Image: A motorcycle safely elevated on both the front and rear BOUDECH Ridelock stands, ready for maintenance.

2.4 Lowering the Motorcycle

1. To lower the motorcycle, gently reverse the lifting process. It is generally recommended to lower the front stand first, then the rear stand.
2. Ensure the motorcycle's side stand or center stand is ready to support the bike as it comes off the stands. Lower the motorcycle slowly and with control.

3. Maintenance

Regular maintenance ensures the longevity and safe operation of your BOUDECH Ridelock Motorcycle Stands.

• Cleaning: Wipe down the stands with a damp cloth after each use to remove dirt, grease, and debris. This helps prevent buildup and maintains the finish.
• Inspection: Periodically inspect all components for signs of wear, damage, or corrosion. Pay close attention to welds, bolts, and adapter connections. Replace any damaged parts immediately.
• Lubrication: Ensure the wheels and any moving parts, such as adjustment mechanisms, are free-moving. Lubricate pivot points and wheel axles as necessary with a suitable lubricant.
• Storage: Store the stands in a dry environment to prevent rust and corrosion. Avoid storing them in areas with high humidity or extreme temperature fluctuations.

4. Troubleshooting

Issue: Motorcycle feels unstable on the stand.

Solution:

• Ensure the motorcycle is on a perfectly flat and level surface. Uneven ground can compromise stability.
• Verify that the stand's width adjustment is correctly set for your motorcycle, providing a snug fit without being too wide or too narrow.
• Confirm that the adapters are properly seated on the swingarm spools/flat swingarm or front forks. Misalignment can lead to instability.
• Always lift the rear wheel first, then the front, to ensure maximum stability during the lifting process.

Issue: Difficulty lifting the motorcycle.

Solution:

• Check if the stand's height and width adjustments are appropriate for your motorcycle model. Incorrect settings can reduce leverage.
• Ensure the stand is positioned as close as possible to the motorcycle's wheels to optimize leverage.
• Confirm the motorcycle's weight does not exceed the 850 lbs capacity of the stand.
• For heavier motorcycles, consider having assistance during the lifting process to ensure safety and ease of use.

5. Product Specifications

6. Warranty Information

This BOUDECH Ridelock Motorcycle Stand Lift is covered by a manufacturer's warranty against defects in materials and workmanship. For specific warranty terms and conditions, please refer to the documentation included with your purchase or contact BOUDECH customer support. Keep your proof of purchase for warranty claims.

7. Customer Support

For technical assistance, parts inquiries, or any questions regarding your BOUDECH Ridelock Motorcycle Stand Lift, please contact your retailer or the manufacturer directly. Please have your model number (Ridelock) and purchase date available when contacting support to expedite the process.
