Introduction
This manual provides comprehensive instructions for the setup, operation, maintenance, and troubleshooting of your Leggett & Platt Prodigy 2.0 Adjustable Bed Base. Please read this manual thoroughly before use to ensure safe and optimal performance of your adjustable bed.
The Prodigy 2.0 adjustable base features a microhook retention system, eliminating the need for a mattress retainer bar. It includes a capacitive-touch remote and a dedicated app for effortless position adjustment.
Safety Information
For safe use of this adjustable bed frame, please ensure that the mattress weight does not exceed the recommended 400 pounds. Be cautious of potential pinch points between the bed frame and mattress, especially near the micro hook retention system. Always follow the provided assembly instructions carefully to prevent instability or collapse, and secure any loose cords or cables to avoid entanglement or tripping hazards.
Setup
Unpacking and Initial Inspection
Carefully remove all components from the packaging. Inspect for any damage that may have occurred during shipping. If any parts are missing or damaged, contact customer support immediately.
Assembly
The Prodigy 2.0 adjustable bed base requires minimal assembly. The primary step involves screwing in the four legs and then carefully flipping the unit over. It is recommended that two strong individuals perform this task due to the weight of the unit (approximately 180 pounds for a Queen size).
- Place the bed base upside down on a clean, flat surface.
- Locate the threaded inserts for the legs on the underside of the base.
- Screw each leg firmly into its designated insert. Do not overtighten.
- With assistance, carefully flip the bed base right-side up and position it in your desired location.
- Plug the power cord into a grounded electrical outlet.
The microhook retention system is integrated into the base, eliminating the need for a separate retainer bar. Ensure your mattress is properly aligned on the base.
Figure 1: The Prodigy 2.0 Adjustable Bed Base in its flat configuration, showcasing the integrated design.
Figure 2: Close-up view of the USB ports located on the side of the bed base, providing convenient charging access.
Operating Instructions
Using the Wireless Remote Control
The Prodigy 2.0 comes with a backlit capacitive-touch remote control. The remote features buttons for head and foot articulation, massage functions, and preset positions.
Figure 3: The wireless remote control with its tabletop holder. The remote features backlit capacitive-touch buttons for various bed adjustments.
- Head Up/Down: Adjusts the head section of the bed.
- Foot Up/Down: Adjusts the foot section of the bed.
- Pillow Up/Down: Adjusts the head tilt feature for optimal neck support.
- Flat: Returns the bed to a completely flat position.
- Massage: Activates the dual massage function with wave settings.
- Snore Button: Activates a preset position designed to alleviate snoring.
- Light: Controls the underbed lighting feature.
- Lock: Locks the remote to prevent accidental adjustments.
- M1/M2: Memory buttons for saving two favorite positions directly on the remote.
- Set: Used to program memory positions.
Using the Bluetooth App
The Prodigy 2.0 can be controlled via an exclusive Bluetooth app available for Apple and Android devices. The app offers additional features, including four memory settings.
To connect the app:
- Download the "LP Comfort Connect" app from your device's app store.
- Ensure Bluetooth is enabled on your smartphone or tablet.
- Open the app and follow the on-screen instructions to pair with your adjustable bed base. The bed may appear as "LP BED CONTROL" or "Okin-#####" in your Bluetooth settings.
The app allows for precise control of all bed functions, including head and foot articulation, massage, and setting custom memory positions beyond the two available on the physical remote.
Video 1: Demonstration of the Leggett & Platt Prodigy 2.0 adjustable bed base's smart features, including app control and integration with smart home systems like Alexa. This video highlights the bed's ability to adjust positions and interact with other smart devices for enhanced comfort and convenience.
USB Charging Ports
The bed base is equipped with 8 USB ports (4 on each side) for convenient charging of electronic devices.
Maintenance
The Prodigy 2.0 Adjustable Bed Base is designed for minimal maintenance. Regular cleaning and inspection are recommended to ensure longevity and proper function.
- Cleaning: Use a soft, damp cloth to wipe down the frame and fabric surfaces. Avoid harsh chemicals or abrasive cleaners.
- Motor and Mechanism Inspection: Periodically check under the bed for any loose wires or obstructions. Ensure the motors operate smoothly and quietly.
- Power Cord: Inspect the power cord for any signs of damage or fraying. If damaged, discontinue use and contact customer support.
No lubrication or internal maintenance is required for the motors or moving parts.
Troubleshooting
| Problem | Possible Cause | Solution |
|---|---|---|
| Bed does not respond to remote/app. | No power, remote batteries low, remote not paired, remote locked. | Check power connection. Replace remote batteries. Re-pair remote/app (refer to pairing instructions in operating section). Unlock remote if locked. |
| Motor makes unusual noise. | Obstruction under bed, loose connection. | Inspect under the bed for any objects obstructing the mechanism. Ensure all connections are secure. If noise persists, contact customer support. |
| Bed does not fully flatten. | Obstruction, mechanism issue. | Check for obstructions. Press the "Flat" button on the remote. If the issue continues, contact customer support. |
| App cannot connect to the bed. | Bluetooth off, app not updated, incorrect pairing. | Ensure Bluetooth is active on your device. Update the app to the latest version. Try re-pairing the device with the bed. Verify the bed's Bluetooth name. |
If you encounter issues not listed here or if the suggested solutions do not resolve the problem, please contact Leggett & Platt customer support.
Specifications
- Model: PRODIGY2-QN
- Size: Queen
- Product Dimensions: 80"L x 60"W x 15"H
- Item Weight: 180 pounds
- Special Features: Adjustable, Wireless control, Bluetooth app, Dual massage with wave, Snore button, Underbed lighting, Wallhugger, Head tilt, Microhook retention system
- USB Ports: 8 (4 on each side)
- Included Components: Microhook retention system, Backlit capacitive touch remote with table top holder
- Manufacturer: Leggett & Platt
- UPC: 753807598101
- ASIN: B01B8DGNL2
- First Available Date: January 29, 2016
Warranty and Support
Warranty Information
Specific warranty details for the Leggett & Platt Prodigy 2.0 Adjustable Bed Base are typically provided with the product packaging or can be obtained directly from Leggett & Platt's official website. It is recommended to register your product upon purchase to ensure full warranty coverage.
Customer Support
For technical assistance, parts replacement, or warranty claims, please contact Leggett & Platt customer support. Refer to the contact information provided in your product documentation or visit the official Leggett & Platt website for current support options.
Note: The USB charging ports are a standard feature. Any claims of them being an extra cost in some reviews may refer to specific retailer bundles or older models. This model includes 8 USB ports as a standard feature.
