XLERATOR Excel Dryer XL-GR 1.1N High Speed Commercial Hand Dryer User Manual

1. Introduction and Overview

This manual provides essential information for the safe and efficient installation, operation, and maintenance of your XLERATOR Excel Dryer XL-GR 1.1N High Speed Commercial Hand Dryer. Please read all instructions carefully before installation and use.

The XLERATOR hand dryer is designed for commercial use, offering a fast and energy-efficient hand drying solution. Key features include:

• High-speed drying in 8-10 seconds.
• Automatic sensor operation for touch-free use.
• Adjustable speed, sound, and heat controls.
• Energy efficiency, using 80% less energy than conventional hand dryers.
• Durable graphite textured cast cover.
• Surface-mounted design.
• Equipped with a noise reduction nozzle.

Figure 1: Front view of the XLERATOR XL-GR 1.1N hand dryer, showcasing its design and certifications including Building Green Approved and UL Certified.

2. Safety Information

WARNING: To reduce the risk of electric shock, fire, or injury to persons, read and follow all instructions and warnings before installing or using this product.

• Installation must be performed by a qualified electrician in accordance with all local and national electrical codes.
• Disconnect power at the circuit breaker before installing or servicing the unit.
• Ensure the power supply matches the voltage requirements specified on the product label (208-277V, 50/60 Hz).
• Do not operate the hand dryer with a damaged cord or plug, or if it has been dropped or damaged.
• Keep hands and foreign objects away from the air outlet during operation.
• This appliance is not intended for use by persons (including children) with reduced physical, sensory, or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.

3. Setup and Installation

The XLERATOR XL-GR 1.1N hand dryer is designed for surface mounting. Proper installation is crucial for optimal performance and safety.

3.1 Mounting Location

• Select a wall location that is structurally sound and can support the unit's weight (approximately 15-17 lbs).
• Ensure adequate clearance around the unit for air circulation and user access.
• Consider ADA compliance; a recess kit is available separately for ADA-compliant installations.

3.2 Electrical Connection

• The unit requires a dedicated electrical circuit.
• Connect to a 208-277V, 50/60 Hz power supply.
• Current draw: 5.6 - 6.2 Amps.
• Wattage: 1160-1490 Watts.
• All wiring must conform to local and national electrical codes.

3.3 Dimensions

Figure 2: Dimensional drawing of the XLERATOR XL-GR 1.1N hand dryer. Width: 11 3/4 inches (298 mm), Height: 12 11/16 inches (322 mm), Depth: 6 11/16 inches (170 mm).

For detailed installation steps, refer to the separate installation guide provided with your unit or available on the manufacturer's website.

4. Operating Instructions

The XLERATOR XL-GR 1.1N hand dryer features automatic, touch-free operation.

4.1 Hand Drying Procedure

1. Wash hands thoroughly.
2. Place hands under the air outlet. The automatic sensor will detect your hands and activate the dryer.
3. Rub hands together gently to remove excess water and ensure even drying.
4. The dryer will automatically shut off once hands are removed from the sensor's range, typically within 8-10 seconds for complete drying.

Figure 3: A user demonstrating the proper use of the XLERATOR hand dryer by placing hands under the sensor for automatic activation.

4.2 Adjustable Settings

The XL-GR 1.1N features internal adjustments for speed, sound, and heat. These settings are typically configured during installation by a qualified technician to suit the specific environment. Consult your installer or the full technical manual for details on adjusting these parameters.

• Speed Control: Adjusts the air velocity.
• Sound Control: Modifies the operating sound level.
• Heat Control: Options include High, Medium, Low, and Off for the heating element.

5. Maintenance

The XLERATOR hand dryer is designed for minimal maintenance. Regular cleaning and occasional checks will ensure optimal performance and longevity.

5.1 Cleaning

• Wipe the exterior cover with a soft, damp cloth and mild, non-abrasive cleaner as needed.
• Do not use harsh chemicals, abrasive cleaners, or solvents, as these can damage the finish.
• Ensure no liquid enters the air intake or outlet grilles.

5.2 Service LED

The unit features an externally visible Service LED. If this LED illuminates, it indicates a potential issue requiring attention. Consult the troubleshooting section or contact customer support.

5.3 Filter Cleaning (If Applicable)

Some models may include an air filter. If your model has a filter, refer to the full technical manual for instructions on how to access and clean or replace it. Regular filter maintenance helps maintain air quality and dryer efficiency.

6. Troubleshooting

This section addresses common issues you might encounter with your XLERATOR hand dryer. For problems not listed here, contact customer support.

7. Specifications

8. Warranty and Support

8.1 Manufacturer's Warranty

The XLERATOR XL-GR 1.1N hand dryer is backed by a 7-Year Limited Manufacturer Warranty. This warranty covers defects in materials and workmanship under normal use and service. For full details regarding warranty terms, conditions, and exclusions, please refer to the official warranty document provided with your product or visit the Excel Dryer website.

8.2 Customer Support

For technical assistance, service inquiries, or to obtain replacement parts, please contact Excel Dryer customer support. When contacting support, please have your model number (XL-GR 1.1N) and purchase date available.

Manufacturer: Excel Dryer

Brand: XLERATOR
