Fenetic Wellbeing Self Propelled Wheelchair User Manual

1. Introduction and Overview

The Fenetic Wellbeing Self Propelled Wheelchair is designed to provide enhanced mobility, comfort, and independence for adults. This lightweight manual wheelchair features 24-inch quick-release wheels, height-adjustable swing-away leg rests, safety brakes, and a cushioned seat, making it suitable for daily use and travel.

This manual provides essential information for the safe and effective use, setup, operation, maintenance, and troubleshooting of your Fenetic Wellbeing wheelchair. Please read it thoroughly before initial use.

Image 1.1: The Fenetic Wellbeing Self Propelled Wheelchair, highlighting its design and features.

2. Key Features

• Easy Transport: Features quick-release 24-inch wheels and a compact folding design, weighing just 19 lbs (with components removed) for convenient storage and loading into vehicles.
• Safe Entry & Exit: Height-adjustable, swing-away leg rests with supportive calf and heel straps ensure stable and secure positioning, facilitating safe and comfortable transfers.
• Comfort Features: Includes a removable seat cushion, padded backrest, and ergonomic 7-inch armrests for superior comfort and support during extended use.
• Secure Design: A built-in lap belt and attendant-operated slowing brakes ensure safety and control, while the sturdy frame provides reliable stability.
• Compact Storage: Folds down to 29" x 10" x 30" dimensions with tool-free wheel removal, fitting easily into car trunks and tight storage spaces.

Image 2.1: Key components and features of the Fenetic Wellbeing Wheelchair.

3. Setup Instructions

Follow these steps to set up your Fenetic Wellbeing wheelchair for first use:

1. Unpack and Inspect: Carefully unpack the wheelchair and remove all protective packaging materials. Inspect the wheelchair for any signs of damage during transit.
2. Unfold the Frame: Place the wheelchair on a flat, stable surface. Gently pull the armrests outwards to unfold the frame until it locks into place. Ensure all locking mechanisms are engaged.
3. Attach Rear Wheels (if detached): If the quick-release rear wheels are detached, align the axle with the wheel hub and push the quick-release button to insert the wheel. Release the button to secure the wheel. Pull on the wheel to ensure it is firmly attached.
4. Attach Leg Rests: Insert the leg rests into the receiving tubes on the front of the frame. Swing them into position and ensure they are securely latched.
5. Position Seat Cushion and Backrest: Ensure the removable seat cushion and padded backrest are properly positioned and secure for comfort.

Image 3.1: The wheelchair in its unfolded and folded states, demonstrating portability.

4. Operating Instructions

4.1. User Transfer

• Ensure the wheelchair is on a flat, stable surface.
• Engage the locking brakes on both rear wheels to prevent movement.
• Swing away the leg rests or remove them if necessary to facilitate a clear path for transfer.
• If needed, flip up or remove the armrests for easier side transfers.
• Once the user is seated, reposition the leg rests and armrests.
• Secure the built-in lap belt for added safety.

4.2. Braking System

• Attendant Brakes: The wheelchair is equipped with attendant-operated slowing brakes on the push handles. Squeeze the levers to slow down or stop the wheelchair. Push the levers down to engage the parking brake.
• Wheel Locks: Independent locking brakes are located on the rear wheels. Push the levers down to engage the wheel locks when the wheelchair is stationary, especially during transfers or when parked.

Image 4.1: Details of the padded backrest, attendant handbrakes, and lap belt for enhanced support and safety.

4.3. Adjusting Leg Rests

• The leg rests are height-adjustable. Loosen the adjustment knob or lever, set the footplate to the desired height, and then tighten the knob/lever securely.
• Ensure the calf and heel straps are properly positioned and secured to prevent feet from slipping off the footplates.

5. Folding and Transport

The Fenetic Wellbeing wheelchair is designed for easy folding and transport:

1. Remove Components: For the most compact fold and lightest weight, remove the seat cushion, padded backrest, and leg rests.
2. Fold the Frame: Pull up on the center of the seat fabric to begin folding the wheelchair frame inwards. Continue until the frame is fully collapsed.
3. Remove Rear Wheels (Optional): For even greater compactness, press the quick-release button on the center of the rear wheel hubs and pull the wheels off the axles.
4. Storage: Store the folded wheelchair in a dry, safe place. The compact dimensions (29" x 10" x 30" when folded) allow it to fit easily into most car trunks.

6. Maintenance and Care

Regular maintenance ensures the longevity and safe operation of your wheelchair:

• Cleaning: Clean the frame with a damp cloth and mild soap. Avoid abrasive cleaners. The seat cushion and backrest can be removed for cleaning as per their fabric care instructions.
• Wheel Inspection: Regularly check the wheels for wear and tear. Ensure the quick-release mechanisms are functioning correctly. The tires are puncture-proof, reducing maintenance needs.
• Brake Check: Periodically test both the attendant brakes and the wheel locks to ensure they engage securely and provide adequate stopping power.
• Fasteners: Check all nuts, bolts, and screws regularly and tighten if necessary. Do not overtighten.
• Storage: Store the wheelchair in a dry environment, away from extreme temperatures and direct sunlight.

7. Troubleshooting

This section addresses common issues you might encounter:

8. Specifications

Image 8.1: Detailed dimensions and weight capacity of the wheelchair.

9. Warranty and Support

For warranty information, product support, or to purchase replacement parts, please contact the manufacturer, Elite Care, or the seller, Fenetic Wellbeing USA.

You can visit the official Elite Care store on Amazon for more information and contact details: Elite Care Store.
