Jesco Lighting WWS1612-PP-30-RGB-Z LED Wall Washer Instruction Manual

1. Product Overview

The Jesco Lighting WWS1612-PP-30-RGB-Z is a WWS Series LED Plug and Play Outdoor Wall Washer designed for architectural and landscape lighting. This fixture features RGB color-changing capabilities, allowing for dynamic illumination effects. It is constructed from aluminum with a bronze finish and utilizes 12 LEDs, providing up to 1044 lumens of brightness. The unit operates on 100-240V AC input voltage and offers a 30-degree beam angle. It is dimmable and can be controlled via app or remote control. The WWS1612-PP-30-RGB-Z is ETL/cETL, CE, and RoHS safety rated, ensuring compliance with safety standards for outdoor use.

This wall washer is designed for easy plug-and-play installation and can be daisy-chained with up to 16 fixtures or a total run of 1,000 feet.

2. Safety Information

• Read all instructions before installation and use.
• Disconnect power before installing, servicing, or cleaning the fixture.
• Ensure the power source matches the fixture's requirements (100-240V AC).
• This product is rated for outdoor use. Ensure all connections are waterproof and sealed appropriately for outdoor environments.
• Do not operate the fixture with a damaged cord or plug.
• Avoid looking directly into the LED light source when illuminated.
• Installation should be performed by a qualified electrician if you are unsure about electrical wiring.
• Keep away from flammable materials.

3. Package Contents

Verify that all components are present before beginning installation:

• Jesco Lighting WWS1612-PP-30-RGB-Z LED Wall Washer Fixture
• Mounting Hardware (screws, anchors)
• Power Cord (A- US style plug)
• User Manual (this document)
• Note: Remote control may be sold separately or included depending on the specific package.

4. Setup and Installation

This fixture is designed for wall mounting. Follow these steps for proper installation:

1. Choose Location: Select a suitable outdoor wall surface for mounting. Ensure the surface is stable and can support the weight of the fixture. Consider the desired beam angle (30°) for optimal light distribution.
2. Mark Mounting Points: Use the fixture's mounting bracket as a template to mark the drill holes on the wall.
3. Drill Holes: Drill pilot holes at the marked locations. Insert wall anchors if necessary for secure mounting.
4. Mount Fixture: Secure the fixture to the wall using the provided mounting hardware. Ensure it is firmly attached and level.
5. Connect Power: Plug the power cord into a compatible 100-240V AC outdoor-rated electrical outlet. Ensure the connection is protected from moisture.
6. Multiple Fixtures (Optional): If connecting multiple WWS Series fixtures, use appropriate outdoor-rated extension cables and connectors. The maximum run is 16 fixtures or 1,000 feet total length. Consult a qualified electrician for complex multi-fixture installations.

This image illustrates the potential effect of the Jesco Lighting WWS1612-PP-30-RGB-Z LED Wall Washer, displaying a building facade illuminated with vibrant green light, highlighting its color-changing capabilities for outdoor architectural lighting.

5. Operating Instructions

The WWS1612-PP-30-RGB-Z LED Wall Washer offers versatile control options for its RGB color-changing and dimming features.

5.1 Power On/Off

Once connected to power, the fixture will illuminate. To turn off, disconnect power or use the control method (app/remote) if available.

5.2 Color Changing and Dimming

The fixture supports RGB color changing and dimming functionalities. These features are typically controlled via:

• Remote Control: If a remote control is provided or purchased separately, refer to its specific instructions for pairing and operation. Common functions include color selection, brightness adjustment, and pre-programmed modes.
• Mobile App: Some models may support control via a dedicated mobile application. Download the official Jesco Lighting app (if available) from your device's app store and follow the in-app instructions for connecting and controlling your fixture.

Note: The specific control method and features may vary. Refer to any supplementary documentation provided with your remote or app for detailed instructions.

6. Maintenance

Regular maintenance ensures optimal performance and longevity of your LED wall washer.

• Cleaning: Periodically clean the glass and aluminum housing with a soft, damp cloth. Do not use abrasive cleaners or solvents, as these can damage the finish or glass. Ensure the fixture is powered off and cool before cleaning.
• Inspection: Annually inspect the power cord for any signs of damage, fraying, or wear. Check mounting hardware for tightness. Ensure all outdoor connections remain sealed and waterproof.
• LEDs: The LEDs are integrated and not user-replaceable. If the LEDs fail, the entire fixture typically requires replacement.

7. Troubleshooting

If you encounter issues with your Jesco Lighting WWS1612-PP-30-RGB-Z, refer to the following common problems and solutions:

If the problem persists after attempting these solutions, contact Jesco Lighting customer support for further assistance.

8. Specifications

9. Warranty and Support

For warranty information, product support, or to purchase replacement parts, please contact Jesco Lighting directly. Keep your purchase receipt as proof of purchase for warranty claims.

Jesco Lighting Contact Information:

• Refer to the official Jesco Lighting website for the most current contact details.
• Look for customer service or support sections on their website.
