AOSU L5P2CA11
AOSU 3K 5MP Outdoor Wired Security Camera with 2600 Lumens Floodlight User Manual
Model: L5P2CA11
1. المقدمة
Thank you for choosing the AOSU 3K 5MP Outdoor Wired Security Camera with 2600 Lumens Floodlight. This manual provides detailed instructions for the installation, operation, and maintenance of your security camera system. Please read this manual thoroughly before use to ensure proper functionality and safety.
2. انتهى المنتجview
The AOSU Floodlight Cam Pro is a high-performance outdoor security camera designed to provide comprehensive surveillance and intelligent lighting. Key features include:
- دقة 3K Ultra HD: 5-megapixel sensor for crystal-clear video, capturing distant details even in low-light conditions.
- الإضاءة الذكية: Two adjustable floodlights up to 2600 lumens, with customizable lighting modes and periods. 270° wide-angle illumination covers up to 10 meters.
- 270° Motion Detection & 360° PTZ Coverage: Three PIR sensors detect motion over a 270° angle, even outside the camera's field of view. The camera rotates 360° horizontally and 90° vertically for complete surveillance.
- 24/7 Continuous Surveillance: Wired connection ensures uninterrupted recording, maintaining stable operation even in extreme cold.
- الكشف الذكي بالذكاء الاصطناعي: Customizable zones and AI detection for people, vehicles, and pets, reducing false alarms.
- Fast Connectivity & Stable Signal: Integrated 2.4 GHz Wi-Fi and Bluetooth with dual external antennas for strong, stable signal and better wall penetration.
- التخزين المحلي: Supports MicroSD cards up to 512GB for loop recording. Optional cloud storage available.
- صوت ثنائي الاتجاه: التواصل مع الزوار أو ردع المتسللين.
محتويات الحزمة
تأكد من وجود جميع المكونات في العبوة:
- AOSU Floodlight Cam Pro
- قاعدة متزايدة
- Installation Hook and Rope
- Junction Box Kits
- دليل المستخدم (هذا المستند)
3. الإعداد والتثبيت
Proper installation is crucial for optimal performance. This camera is designed for wired installation.
احتياطات السلامة
- تحذير: Always ensure the power supply is disconnected before performing any wiring or installation.
- Consult a qualified electrician if you are unsure about electrical wiring.
- Install the camera in a location that provides a clear view of the area you wish to monitor and is within Wi-Fi range.
خطوات التثبيت
- اختر موقع التركيب: The camera supports both wall and ceiling mounting. Select a location that offers the best coverage and is within reach of your power source.
- تحضير الأسلاك: Turn off the main power supply to the installation area. Connect the camera's wires to your existing electrical wiring using the provided junction box kits. Ensure all connections are secure and insulated.
الصورة: مفصلة view of the wired installation process, showing the junction box and electrical connections.
Before wiring, the power supply must be cut! - تركيب الكاميرا: Secure the mounting base to the wall or ceiling using appropriate screws and anchors. Attach the AOSU Floodlight Cam Pro to the mounting base.
Image: The AOSU Floodlight Cam Pro, showing its two floodlights and camera lens, ready for installation.
Image: Illustration of the camera mounted on both a ceiling and a wall, demonstrating flexible installation options.
- اعادة الطاقة: Once the installation is complete and all connections are secure, restore power to the circuit.
- اقتران التطبيق: Download the AOSU app from your smartphone's app store. Follow the in-app instructions to pair your camera using 2.4 GHz Wi-Fi and Bluetooth.
4. تعليمات التشغيل
This section details the primary functions and how to operate your AOSU Floodlight Cam Pro.
Camera Features and Controls
- يعيش View: Access real-time video feed through the AOSU app.
- تحكم PTZ: Use the app to pan (360°) and tilt (90°) the camera lens to adjust the viewزاوية جي.
Image: An illustration showing the camera's 360-degree horizontal and 90-degree vertical rotation capabilities for comprehensive coverage.
- صوت ثنائي الاتجاه: استخدم الميكروفون ومكبر الصوت المدمجين للتواصل ثنائي الاتجاه.
Image: A visual representation of the two-way audio function, showing a person speaking into a phone and the camera transmitting the audio.
- التحكم في الأضواء الكاشفة: Adjust brightness (up to 2600 lumens) and set lighting schedules via the app. The floodlights can be activated by motion.
Image: A night scene showing the powerful 2600 lumens illumination provided by the camera's floodlights, turning night into day.
- Motion Detection & AI Tracking: The camera uses three PIR sensors for 270° motion detection. AI algorithms identify humans, vehicles, and pets, triggering alerts and recording.
Image: An illustration demonstrating the camera's 270-degree motion detection range using three PIR sensors, covering areas even outside the direct camera view.
Image: A scene showing the camera's AI capabilities to recognize and track humans, vehicles, and pets, with bounding boxes indicating detected objects.
- التسجيل والتخزين:
- تسجيل متواصل على مدار الساعة طوال أيام الأسبوع: The wired connection enables continuous recording.
Image: An icon indicating 24/7 recording, with the camera shown active at night, emphasizing continuous surveillance.
- التخزين المحلي: Insert a MicroSD card (up to 512GB, not included) for local loop recording.
Image: A close-up of the camera showing the MicroSD card slot, with a MicroSD card being inserted, highlighting the local storage option.
- التخزين السحابي: Optional cloud storage is available with a 30-day free trial.
- تسجيل متواصل على مدار الساعة طوال أيام الأسبوع: The wired connection enables continuous recording.
- مناطق قابلة للتخصيص: Define specific activity zones to focus surveillance and trigger alerts only when motion is detected in those areas.
الصورة: صورة علوية view of a driveway with a car, showing a blue shaded area representing a customizable activity zone for focused surveillance.
- الرؤية الليلية: The camera provides clear night vision, enhanced by the floodlights for color night vision.
Image: A high-resolution image of a car in a driveway, with an inset showing a magnified view of a license plate, demonstrating the 3K UHD clarity.
- التحكم الصوتي: Compatible with Amazon Alexa and Google Assistant for smart home integration.
Image: A smart display showing the camera's live feed, with "Works with Alexa" and "Ok Google" logos, indicating voice control compatibility.
Using the AOSU App
The intuitive AOSU app allows for easy control and management of your camera. Features include:
- Viewing live feed and recorded footage.
- Receiving instant alerts for detected motion.
- Customizing detection settings and activity zones.
- Managing storage options (local and cloud).
- Accessing event history and downloading videos.
Image: A smartphone screen displaying the AOSU app's daily overview, showing a timeline of events and video thumbnails, allowing easy review وتنزيلها.
5. الصيانة
تضمن الصيانة الدورية طول عمر الكاميرا وأدائها الأمثل.
- تنظيف: نظّف عدسة الكاميرا وأسطح الكشاف بشكل دوري باستخدام قطعة قماش ناعمة.amp قماش. تجنب المنظفات الكاشطة.
- تحديثات البرامج الثابتة: Check the AOSU app regularly for firmware updates. Keeping your camera's firmware up-to-date ensures access to the latest features and security enhancements.
- مقاومة الطقس: The camera is designed to withstand various weather conditions (IP65 rated). However, ensure proper installation to prevent water ingress.
Image: The camera shown in rainy and snowy conditions, illustrating its weather-resistant design for reliable surveillance in harsh weather.
6. استكشاف الأخطاء وإصلاحها
If you encounter issues with your AOSU Floodlight Cam Pro, refer to the following common problems and solutions:
| مشكلة | السبب المحتمل | حل |
|---|---|---|
| الكاميرا لا تعمل. | لا يوجد مصدر للطاقة، الأسلاك غير صحيحة. | Check power connections and ensure the circuit breaker is on. Verify wiring according to installation instructions. |
| غير قادر على الاتصال بشبكة Wi-Fi. | كلمة مرور الواي فاي غير صحيحة؛ الكاميرا بعيدة جدًا عن جهاز التوجيه؛ تم اختيار شبكة 5 جيجاهرتز. | Ensure correct 2.4GHz Wi-Fi password. Move camera closer to router or use a Wi-Fi extender. The camera only supports 2.4GHz Wi-Fi. |
| تنبيهات حركة خاطئة متكررة. | Sensitivity too high; environmental factors (e.g., moving branches). | Adjust motion detection sensitivity in the app. Define activity zones to exclude irrelevant areas. Utilize AI detection for specific object types. |
| جودة الفيديو سيئة. | عدسة متسخة؛ إشارة واي فاي ضعيفة؛ ظروف إضاءة منخفضة. | Clean the camera lens. Ensure strong Wi-Fi signal. Verify floodlights are functioning correctly for night vision. |
| بطاقة MicroSD لا تسجل. | Card full; card not formatted; incompatible card. | Check card capacity. Format the MicroSD card via the app. Ensure the card is up to 512GB and a compatible class. |
For further assistance, please contact AOSU customer support.
7. المواصفات
| ميزة | التفاصيل |
|---|---|
| رقم الموديل | L5P2CA11 |
| دقة الفيديو | 3K (5 ميجا بكسل) |
| سطوع الضوء الكاشف | تصل إلى 2600 لومن |
| زاوية كشف الحركة | 270 degrees (PIR sensors) |
| PTZ Coverage | 360 درجة أفقيًا و90 درجة رأسيًا |
| الاتصال | Wired, Wi-Fi (2.4 GHz), Bluetooth |
| التخزين المحلي | بطاقة MicroSD (تصل إلى 512 جيجابايت) |
| مصدر الطاقة | AC 240 Volts, 24 Watt-hours |
| الأبعاد (الطول × العرض × الارتفاع) | 24 × 23 × 23 سم |
| وزن | 2 كيلوغرام |
| مقاومة الماء | IP65 (Impermeable) |
| درجة حرارة التشغيل | Maintains stable operation in extreme cold. |
| الأجهزة المتوافقة | الهاتف الذكي والكمبيوتر اللوحي |
| نوع وحدة التحكم | أمازون أليكسا، أندرويد، مساعد جوجل |
8. الضمان والدعم
معلومات الضمان
The AOSU Floodlight Cam Pro comes with a ضمان الشركة المصنعة لمدة 12 شهرًا يسري هذا الضمان من تاريخ الشراء. ويغطي عيوب المواد والتصنيع في ظل الاستخدام العادي. ولا يغطي الأضرار الناجمة عن سوء الاستخدام أو الحوادث أو التعديلات غير المصرح بها أو الكوارث الطبيعية.
يرجى الاحتفاظ بإثبات الشراء الخاص بك لمطالبات الضمان.
دعم العملاء
For technical support, warranty claims, or any questions regarding your AOSU product, please visit the official AOSU website or contact their customer service team. Contact information can typically be found on the product packaging or the AOSU official webموقع.
الموارد المتاحة على الإنترنت:
- AOSU Official Webموقع: www.aosu.com (ملاحظة: هذا عنصر نائب URL, please refer to actual product documentation for correct support links.)
- AOSU Store on Amazon: Visit AOSU Store
